Product parameters
|
|
| Battery type | Lithium iron phosphate (LiFePO₄) |
| Battery capacity [kWh] | 8kWh |
| Battery cell lifespan | 11000 cycles@25℃, 100%DOD, 0.5P. @70%SOH |
| Product lifespan | Cycle life: >8000 cycles@20 - 25℃@100A @90%DoD Cycle life: >8000 cycles@20 - 25℃@100A @90%DoD |
| Rated voltage [Vdc] | 25.6 [VDC] |
| Discharge voltage range [Vdc] | 21.6 - 28.4 [VDC] |
| Charging voltage range [Vdc] | 21.6 - 33.4 [VDC] |
| Suggested charging and discharging currents [A] | 100 A |
| Maximum charging and discharging current [A] | 200 A |
| Discharge depth [%] | 90% |
| Charging mode | CC - CV |
| Charge and discharge port | M8 bolt |
| Built - in communication port | CAN/RS485/RS232; Wifi/Bluetooth (optional) |
| Built - in screen | Yes. LCD touch screen |
| Scalable (maximum number of parallel units) | Up to 16 battery packs. 128kWh |
| Compatible with inverter brands | Hithium/Victon Energy/Deye/Eotronic/SMA/GoodWe/Growatt/TBB/MUST/... |
| IP level | IP30 |
| Suggested working temperature [℃] | Charging: 0℃ - 40℃ Discharging: -20℃ - 40℃ Storage: -20 to 60℃ |
| Suggested storage temperature [℃] | -20 to 60℃ |
| Protection function | Over - temperature protection, under - temperature protection, overcharge protection, overcurrent protection, short - circuit protection, under - voltage protection, reverse connection protection, failure protection |
| Humidity [%] | 10% - 90%RH |
| Working altitude | ≤3000m |
| Cooling | Natural cooling |
| Size [mm] | L540.6W240H501.2mm(excluding outer box)/L600W310H510mm(including outer box) |
| Weight [kg] | Approximately 66kg (net weight)/83kg(gross weight including wooden box) |
| Wheel | 4 |
| Certification | UN38.3/MSDS/EC62619 |
